Limit Switch
Defined position of the cable entry
Available with or without integrated level transmitter
Different electrical connections available
Individual shortening and twisting of the rod is possible
Sensor completely made of stainless steel (protection type IP69K)
CIP / SIP cleanable up to 140 °C
Type of protection is IP69K
Applications
level detection of fluid and conductive media in vessels and pipes
(min. conductivity 1µS/cm but depending on the transmitter)
Full- / empty detection in vessels, Dry running protection of pumps
Overfill protection in dosing plants
Ultrasonic Flowmeter
Ultrasonic Doppler principle
Not influenced by temperature fluctuations and conductivity
Very short reaction time
High accuracy up to 140°C
fws-141 with free programmable set point
fwa-141 with analog or frequency output (switchable)
Indicator switching output with LED
Applications
Drinking water juice milk emulsions CIP-media
Monitoring of flows in pipes (0,1... 2,5m/s)
Turbidity limit of monitoring is 1NTU, particle size: >50µm
Measuring of flow velocities and flow volume
Flow monitoring, set point free programmable
Monitoring of pumps, filters, etc., dry-run protection
Monitoring of cooling loops, valves
Measuring of leckages with 2x fwa-141 and evaluation device pem-dd
Evaluation of batch processes
Turbine Flow Meter
Patented, frontflush sensor
Independent to reflexions at small diameters or electro-polished surfaces
100% compatible to antecessor ITM-2, mechanical and electrical
No·color dependency (wave length 860 nm)
Smallest pipe diameter DN25
Four measurement ranges, two externally switchable
High reproducibility ≤1% of full scale
Switching output (switchpoint and hysteresis free adjustable)
Analog output 4 ...20mA (standard)
Pressure: 16 Bar Max.
CIP / SIP-cleaning up to 140°C /maximum 30 minutes
Product contacting materials compliant to FDA
Sensor made of stainless steel, immersion piece made of PEEK
Applications
Phase·separation of products (for example whey·–·cream·–·milk)
CIP-return line (monitoring of pre-rinse water to product leftovers)
Yeast harvest in breweries
Quality control
Leackage control of filter and gaskets
Pressure Sensor SENSOR
Robust design
Piezoresistive measurement cell
Defined PG position
Integrated two-wire measuremet transmitter 4-20mA
CIP-cleanable up to 120 °C max
Front-flush stainless stell sensor cell
FDA konform sensor materials
Sensor completely made of stainless steel
Type of protection is IP69K
Further process connections:
TriClamp, diary flange, SMS, DRD, Varivent, BioControl
Applications
Accurate hydrostatic level measuring in vessels and tanks
Precise pressure measuring in pipes and vessels
Pressure monitoring
Compressed Air
Nitrogen
Argon
Inductive Conductivity Meter
Wearless inductive measurement principle
Precise measurment by compensation of temperature
High reproducibility of ≤ 1 % of measurement value
Analog output for conductivity and temperature as standard
Installation in pipes from DN 40 possible
Product contacting materials compliant to FDA
Sensor made of stainless steel, bobbin case made of PEEK
Certification acc. to sanitary 3-A standard 74- 03
Pressure: 10 Bar Max.
Temperature Ranges: ambient: -10...+60 °C
Process: 0...100 °C
CIP- / SIP cleaning up to 140 °C / 30 minutes max.
Protection Class: IP69 K (with M12 plug in)
Applications
Controlling of CIP processes (e. g. phase separation detergents / water)
Concentration measurement (e.g. Alkali and acid concentration in remaking)
Monitoring of product quality, quality control
Magnetic Inductive Flowmeter
High measurement accuracy even at low flow rates
Simple and user-friendly parameterization
Automatic empty pipe detection avoids undefi ned readings for empty pipes
PFA lining for maximum resistance to aggressive substances such as acids & bases
Vacuum-tight, rigid meter tube lining, even at high temperatures
Swiveling housing head with illuminated graphic display
Operation of device via optical keys without opening the housing
Minimal maintenance and care requirements
Pharmaceutical version available with all necessary certificates
Sensor made entirely of stainless steel
EHEDG-compliant, hygienic design
All parts in contact with the product are FDA-compliant
Transmitter made of PFA; vacuum-tight and piggable
Process connection made of stainless steel 1. 4404
Electrodes made of stainless steel 1. 4404 with inspection certifi cate 3.1
CIP/SIP cleaning up to max. 130 °C (max. 30 minutes)
Large selection of process adapters
Applications
Measurement of fl ow rate and volume in food and pharmaceutical applications
Suitable for liquids, mash and pastes with a minimum conductivity of 5 μS/cm
Precise measurement of media containing solids (< 5 % solid particle content)
Measurement range from 30 l/h to 640 000 l/h
Suitable for dosing and fi lling applications
